Don’t leave the Mercury in your rivers! It’s a contaminant that won’t go away. Eventually, the fish eat it. You eat the fish. Then we all have a problem!
Contact us today to find out how Shell Dredging can clean up your rivers and make your country beautiful again!

SPECIFICATIONS AND OPERATIONS

10 Inch Dredge 12 Inch Dredge 15 Inch Dredge
CAPACITY: 200 YARDS/HR 300 YARDS/HR. 400 YARDS/HR.
WEIGHT: 8 TONS 25 TONS 55 TONS
HEIGHT: 12 FEET 24 FEET 24 FEET
LENGTH: 40 FEET 80 FEET 120 FEET
WATER: 2,000 GPM (Can be recirculated) 6,000 GPM (Can be recirculated) 8,000 GPM (Can be recirculated)
WIDTH: 26 FEET 26 FEET 26 FEET
COST: $2 million USD $3.5 million USD $5 million USD
POWER PLANT: One GMC172 diesel engine delivering 700 continuous horsepower drives a 200 GPM water pump and a 250 KW generator (3-phase, 220/110). Two diesel engines delivering 1013 continuous horsepower drives a 7,000 GPM water pump and a 250 KW generator (3-phase, 220/110). Diesel engine delivering in excess of a 1000 continuous horsepower drives a 10,000 GPM water pump and a 450 KW generator (3-phase, 220/110).
OPERATIONS Two men per shift can operate
Powered by two cat engines:
733 hp & 3406-280 hp
200 psi water pump
250 KW 3-phase, 220/110-volt generator
air compressor
Centrally-located electrical & air-generated controls
Designed to operate on a river or pond.
Needs at least three feet of water to start operating
Two men per shift can operate
Powered by two cat engines:
733 hp & 3406-280 hp
200 psi water pump
250 KW 3-phase, 220/110-volt generator
air compressor
Centrally-located electrical & air-generated controls
Designed to operate on a river or pond.
Needs at least three feet of water to start operating
Four men per shift can operate
Powered by Cummins diesel gen-set 450KW:
733 Continuous HP
200 psi water pump
250 KW 3-phase, 220/110-volt generator
air compressor
Centrally-located electrical & air-generated controls
Designed to operate on a river or pond.
Needs at least three feet of water to start operating
